Product code: AO-MFE-02
Producer: SECTRON

Connector MCX(f)straight 2, EDGE

Product code: AO-MFE-02
Producer: SECTRON

Connector MCX(f)straight 2, EDGE

Connector straight MCX (female) is designed for soldering to the panel.

2.07incl. VAT (21%) / pc

excl. VAT 1.71 € / pc

Price from 10 pieces 1.29 €

Price from 100 pieces 1.07 €

In stock
i
- +
Add to compare

If the customer is not registered for VAT, the rate according to his country of residence will be added.

Detailed description

Connector MCX (female) straight 2, EDGE

These are coaxial connectors with a latch mechanism. They are compatible with SMB connectors but are 30% smaller than SMB connectors. The dimensions of the internal contact and the insulator are the same. The impedance of the connector is either 50 Ohm with an operating frequency range up to 6 GHz or 70 Ohm with an operating range up to 3 GHz. They are characterized by high reliability and mechanical stability. They are also used as standard connectors in GPS devices, WLAN networks, fixed and mobile communications.

Connector MCX (female) is designed for soldering to the panel.

Material and finish:

• Body: Brass / Thin Gold over Nickel
• Socket Contact: Berylium Copper / Gold 0.13um min over Nickel
• Insulator: PTFE / -

Parameters:

• Type: Female
Impedance: 50 Ω
• Insulation resistance: 1 000 MΩ
• Center contact resistance: 5 mΩ
• Outer contact resistance: 1 mΩ
• Maximum frequency: 0-6 GHz
 Mating cycles: 500 cycles
• Operating temperature: - 65 °C to + 165 °C
• Weight: 1.8 g

Technical parameters can be found in the attached datasheet.
