Product code: AO-AGSM-SA1S
Producer: SECTRON

Antenna GSM Adhesive 25, 4.6 dBi, SMA(m), RG174U/3m

Product code: AO-AGSM-SA1S
Producer: SECTRON

Antenna GSM Adhesive 25, 4.6 dBi, SMA(m), RG174U/3m

Omnidirectional adhesive antenna with an SMA (m) connector. It is designed for receiving/transmitting GSM signal.The antenna operates in bands 800/900/1700/1800 MHz.

6.95incl. VAT (21%) / pc

excl. VAT 5.74 € / pc

In stock
i
- +
Add to compare

If the customer is not registered for VAT, the rate according to his country of residence will be added.

Detailed description

Omnidirectional GSM antenna

Omnidirectional adhesive antenna for* GSM technologies*. The antenna operates in bands 900/1800 MHz. Used in vehicles to connect to cellular modems and routers. Is suitable for sticking to glass. It is supplied with 1 m cable with SMA (m) connector. Easy installation is ensured by double-sided 3M tape.

Connector specifications SMA:

These are high-frequency connectors with screw connection mechanism. The characteristic impedance of the connector is 50 Ohm and the operating frequency range up to 18 GHz. There are two types of SMA connectors, namely SMA and RP-SMA. The connection and disconnection of the connectors is guaranteed for up to 500 cycles. Temperature range is -65 °C to +165 °C. Most of the current cellular routers are equipped with SMA connectors for connecting Wi-Fi / 2G / 3G / LTE / GPS antennas terminated by proticates. It is also used as a standard connector in RF measuring technology. They are characterized by high reliability, durability, high mechanical stability and optimal electrical properties.

Cable specifications RG174 / U:

The cable labeled RG174 / U is a basic variant of a coaxial cable that is compatible with connectors applicable to a cable diameter of 2.8 mm. The characteristic impedance of the cable is 50 Ω. The reduction factor is fixed at 0.66. The operating temperature range is -20 to 80 °C.
It is most often used for creating cable adaptors with connectors such as BNC / FAKRA / FME / MCX / MMCX / N / SMA / SMB / SMP / TNC and others. It is ideal for short and bending stressed connections in measuring and telecommunications technology, for GPS / GSM / WLAN antennas, antenna leads etc.

Technical parameters can be found in the attached datasheet.

Parameters

Impedance 50  Ohm Cabel RG174/U
Connector SMA(m) Maximum input power 10  W
Polarization Linear Execuion External
Operating temperature -30 ~ +80  °C Dimensions 129.5 x 22.8 x 6.7  mm
Directivity Omnidirectional Technology GSM
Weight 52.75  g Gain 4.6  dBi
VSWR <2.0:1 Radiation angle H 360 V 30
Type of attachment Adhesive

6.95incl. VAT (21%) / pc

excl. VAT 5.74 € / pc
