Antenna GSM/UMTS Adhesive 90 Flexi, Quad-band, 9dBi, SMA(m), RG58/5m

Product code: AO-AUMTS-SA9S5-FLEXI
Producer: SECTRON

Antenna GSM/UMTS Adhesive 90 Flexi, Quad-band, 9dBi, SMA(m), RG58/5m

Omnidirectional antenna for GSM and UMTS technologies. The antenna operates in frequency bands 900/1800/1900/2100 MHz.

16.07incl. VAT (21%) / pc

excl. VAT 13.28 € / pc

Temporarily unavailable
i
Temporarily unavailable Add to compare

If the customer is not registered for VAT, the rate according to his country of residence will be added.

Detailed description

Omnidirectional GSM/UMTS antenna

Omnidirectional antenna for GSM and UMTS technologies. The antenna operates in frequency bands 900/1800/1900/2100 MHz. The antenna is suited for modems and routers. A cable with a length of 5 m is attached to the antenna, which is terminated with SMA (m) connector. In addition, it is equipped with double-sided 3M tape, which ensures easy mounting, for example, on glass or plastic.

Connector specifications SMA:

These are high-frequency connectors with screw connection mechanism. The characteristic impedance of the connector is 50 Ohm and the operating frequency range up to 18 GHz. There are two types of SMA connectors, namely SMA and RP-SMA. The connection and disconnection of the connectors is guaranteed for up to 500 cycles. Temperature range is -65 °C to +165 °C. Most of the current cellular routers are equipped with SMA connectors for connecting Wi-Fi / 2G / 3G / LTE / GPS antennas terminated by proticates. It is also used as a standard connector in RF measuring technology. They are characterized by high reliability, durability, high mechanical stability and optimal electrical properties.

Cable specifications RG58/U:

Kabel koncentryczny RG58 jest kompatybilny ze złączami stosowanymi do kabla o średnicy 5 mm. Przewód ten jest przeznaczony do stosowania w zakresie częstotliwości 0–1 GHz, może być również stosowany do wyższych częstotliwości, ale kosztem wyższego tłumienia. Impedancja kabla wynosi 50 Ω. Współczynnik skrócenia ustalono na 0,66. Zakres temperatury roboczej wynosi od -20 do 75 ° C. Kabel jest używany do produkcji anten zewnętrznych WiFi/GPS/GSM.
Najczęściej jest używany do produkcji RF konektorów antenowych ze złączami takimi jak BNC / FAKRA / FME/ N / SMA/ TNC itp .

Technical parameters can be found in the attached datasheet.

Parameters

Impedance 50  Ohm Cabel RG58/U
Connector SMA(m) Maximum input power 10  W
Polarization Linear Execuion External
Operating temperature -40 ~ +85  °C Dimensions 331.7 x 70  mm
Directivity Omnidirectional Technology GSM , UMTS
Weight 247.82  g Gain 9  dBi
VSWR <2.0:1 Radiation angle H 360 V 30
Type of attachment Adhesive
