Antenna LTE Embedded FLEX G142, 3 dBi, IPEX MHF(f) RA, 1.13mm Coaxial Cable/100mm

Product code: AO-ALTE-FPCG142I100
Producer: SECTRON

Antenna LTE Embedded FLEX G142, 3 dBi, IPEX MHF(f) RA, 1.13mm Coaxial Cable/100mm

Directional antenna suitable as receiver/transmitter of signal in LTE. Antenna operates in bands 700/800/900/1700/2400/2600 MHz.

5.82incl. VAT (21%) / pc

excl. VAT 4.81 € / pc

Temporarily unavailable
i
Temporarily unavailable Add to compare

If the customer is not registered for VAT, the rate according to his country of residence will be added.

Detailed description

Directional LTE antenna

Directional antenna suitable as receiver/transmitter of signal in LTE. Antenna operates in bands 700/800/900/1700/2400/2600 MHz. It is suited for modems/routers. It is supplied with 10 cm cable Hirose 068  with an IPEX MHF connector.

Specifications connector IPEX MHF:

IPEX MHF connectors are compatible with U.FL connectors for applications where there is very little space for connecting / interconnecting RF components. The characteristic impedance of the connector is 50 Ohm and the operating frequency range up to 9 GHz.

Specifications cable Hirose 068:

The Hirose 068 coaxial cable is compatible with connectors that are applicable to a 1.13 mm cable diameter. Due to its features and size, it is widely used in applications that require high-frequency transmission using miniature coaxial connections. It is suitable for applications involving RF communication equipment, as well as electronic measuring instruments. It is most often used for creating cable adaptors with connectors such as U.FL / SMA / FME / MCX / TNC and others. The resulting cable adaptors are most often used to connect external antennas to eg cellular modules or IoT / NB-IoT / WiFi / GNSS and other RF devices.

More information can be found in the attached datasheet.

Parameters

Impedance 50  Ohm Cabel RF 1.13
Connector IPEX-MHF(f) R/A Maximum input power 10  W
Polarization Linear Execuion External
Operating temperature -40 ~ +85  °C Dimensions 110 x 20  mm
Directivity Directional Technology LTE
Gain 3  dBi VSWR <3.0:1
Radiation angle H 30 V 180 Type of attachment Adhesive
