Connector SMB(m)cable straight, THD

Product code: AO-BMT-05 /Manufacturer: SECTRON

2.71 EUR Without VAT

In stock When do I get the item?

Price from 10 pieces 2.04 EUR

Price from 100 pieces 1.70 EUR

guarantee 24 months
Subject*
Name and surname*
E-mail*
Inquiry*
By submitting the form, you agree to the privacy policy.
Your name and surname*
E-mail*
Send e-mail*
Message*
By submitting the form, you agree to the privacy policy.

Description

Connector SMB (m) straight, THD

SMB coaxial connectors are characterized by high reliability and mechanical stability. Snap-on mechanism provides fast and reliable connection. The characteristic impedance of the connector is 50 Ohm and the working frequency ranges up to 4 GHz. They are used, for example, to connect wireless WLAN devices, test devices and GSM / GPS / Wi-Fi antennas.

The connector is designed for mounting on a PCB using the THD method.

Material and finish:

• Insulator 1: PTFE / -
• Insulator 2: PTFE / -
• Cover: brass / gold-plated nickel
• Body: brass / gold-plated nickel
• Ferulle: brass / gold-plated nickel
• PIN: brass / gold 0.13 μm min over nickel

Parameters:

 • Type: Male (m)
 • Impedance: 50 Ω
 • Maximum Frequency: 0-4 GHz
 • Insulation Resistance: 1 000 MΩ
 • Mating Cycles: 100
 • Temperature range: - 20 °C to + 85 °C

Technical parameters can be found in the attached datasheet or contact our sales department.

Parameters

Connector: SMB(m)
