Robustel MG460: Maritime Gateway Certified to IEC 61162-460 Ed. 3 and IACS UR E27
The Robustel MG460 is a maritime cybersecurity gateway fully compliant with IEC 61162-460 (Ed. 3) and IACS UR E27 standards. As the world’s first product to receive DNV type approval for both 460-Gateway and 460-Wireless Gateway, it establishes a certified security barrier that reliably protects navigation and radio communication systems during data exchange between ship and shore.
Use Cases for the Robustel MG460 Gateway
- Secure VDR and Navigation Data Exchange: The MG460 enables encrypted export of VDR logs and approved bridge data to shore via secure tunnels. Files pass through an isolated DMZ, with individual firewalls ensuring domain separation in accordance with IEC 61162-460 and UR E26/E27 regulations
- ECDIS Map Updates and Firmware Distribution: With the MG460, you can safely deliver electronic navigational chart updates and signed firmware from shore to onboard servers via a controlled DMZ. Policy rules and audit logs protect critical networks during updates, minimising the risk of cyber threats
- IMO DCS Reporting and CII Calculation: The gateway supports the collection and processing of fuel consumption data and CII metrics onboard. Encrypted export of this data to shore or regulatory bodies complies with IEC 61162-460 and IACS UR E26/E27 standards.
Cybersecurity Features and Functions
The MG460 is equipped with a multi-layer inspection firewall, allowing custom rules for each interface. The isolated DMZ ensures controlled file and service exchange, while VPN tunnels enable encrypted, auditable data transfers without exposing critical onboard systems.
Hardware Specifications
The Robustel MG460 features five Gigabit Ethernet ports (4× WAN + 1× LAN or 5× LAN), each protected by its own firewall. It also offers two serial ports (RS-232/422/485), two digital inputs (DI), and two relay outputs, along with three USB ports and a microSD card slot for long-term data storage. For reliable communication, the gateway is equipped with dual-SIM technology. The integrated GNSS module (GPS, Galileo, GLONASS, QZSS, BDS) enables precise positioning and real-time tracking.
Compliance with Standards and Regulations
The Robustel MG460 is fully compliant with UR E26/E27, mandatory for all newbuild vessels since July 1, 2024. Cross-references to IEC 61162-460 Ed. 3 make it a standardised solution for modern fleets requiring cyber-resilient and secure systems.
Remote Management with RCMS
The MG460 runs on Linux and supports the RCMS platform, designed for remote management, monitoring, and configuration of Robustel devices. This service is particularly valuable for vessels operating in remote areas where on-site maintenance is challenging. RCMS provides real-time insights into network status, including device location, data usage, signal strength, and connection status.
Key Features of the Robustel MG460 Maritime Gateway
- Complies with IEC 61162-1, IEC 61162-2, IEC 61162-460 Ed. 3, and IEC 60945.
- DNV certified (460-Gateway and 460-Wireless Gateway).
- High-performance 1.6 GHz CPU + 64 GB eMMC flash for complex applications.
- DMZ with file storage and application services for secure connectivity.
- Remote secure access via VPN tunnel.
- 5× 1000 Mbps Ethernet ports (4× WAN + 1× LAN or 5× LAN)
- 2× RS232/RS422/RS485 (software-configurable) for industrial/legacy devices.
- 2× DI and 2× relay outputs for monitoring and control.
- MicroSD slot for logging system protocols and navigation data.
- Linux Debian OS for user software development and deployment.
- GNSS and WiFi technology (IEEE 802.11 a/b/g/n/ac/ax).
- Industrial design for uninterrupted network connectivity.
- RCMS supports efficient device management via RobustVPN.
Package Contents
- 1× Robustel MG460 Gateway
- 1× Wall or DIN rail mounting kit
Technical parameters can be found in the attached datasheet.
